Gauges

We supply a complete range of differential pressure and float level gauges for all size and types of cryogenic vessels & trailers.

From the standard through to the next generation, there will be a gauge for your application, that not only beats competitors on quality, but also on delivery, price, performance and service.

Combined DP & Pressure Gauge

The combined DP and pressure gauge options have a ±2% full scale accuracy. This type of diaphragm model is used in applications where no migration of the media from high pressure side (HP) to low pressure side (LP) is permitted.  Options include oxygen cleaned and switch options, 1 & 2, for remote outputs.

  • Accuracy: ±2% of the FSD (Ascending)
  • Migration: Zero Migration from high to low port
  • Range: 0-0.075 to 0-7 bar (0-1 to 0-100 psi)
  • First marking on scale: 15% of the FSD
  • Mounting: Direct, front flange, 2” pipe & surface mounting
  • Case material & dial size: Stainless steel (SS 304): 150mm
  • Wetted Parts: Diaphragm, body material, SS 302 spring & ceramic magnet
  • Maximum Working Pressure: 75 bar / 1000 psi
  • Design Temperature: -40°C to 80°C / -40°F to 175°F
  • Body Material: Aluminium, Brass, SS 316
  • Window: Float, Toughened glass, acrylic & safety glass
  • Connection: Standard: ¼” BSP (F) Optional: ¼” NPT (F) with adaptor
  • Porting: In-line, rear, bottom, bottom & vent, in-line & vent, in-line & bottom, Barton replacement adapters
  • Protection: IP 65 / NEMA-4
  • Diaphragm: Buna-N, Viton, Silicon
  • Scale: Standard Pressure unit, Volumetric & weight (need detailed internal tank drawing)
Combined DP & Pressure Gauge front 400

Digital Cryogenic Level Gauge

Our new digital cryogenic tank level pressure gauge with 4-20mA output is used on many cryogenic vessel applications.  This high accuracy digital level and pressure gauge has a large display screen and backlight.  It comes EMI-EMC tested by TÜV and is supplied with the CE statement of conformity.

  • Output: 4-20mA (2- wire)
  • Display Size: 67 x 31 mm , digit height 17 mm with backlight
  • Scale: Standard Pressure unit, Volumetric & weight (need detailed internal tank drawing)
  • Mounting: Direct Mounting
  • Static/Maximum working pressure: 400bar
  • Design Temperatures: -40°C to 80°C / -40°F to 175°F
  • Body Material: SS 316 (Std.)/Aluminium
  • Wetted Parts: Sensor in SS316, body material
  • Seal: Buna-N, Viton , EPDM (Others on request)
  • Connection: Standard: ¼” BSP(F), Optional: ¼” NPT (F), others through adaptor
  • Porting: In-line, rear, bottom, bottom & vent, in-line & vent, in-line & bottom
  • Protection: IP 66 / NEMA-4
  • Calibration Range: 0.06 bar – 10bar
  • Overload Pressure: 160bar (one side)
Digital Cryogenic Level Gauge front 400

Float Level Gauge

The CR float level gauge is used in liquid cylinders globally.  This robust gauge is designed to fit into your new or existing cryogenic liquid cylinders with ±10% accuracy.  With connections to fit all liquid cylinders globally - and numerous wetted part options - there is a standard option for all your requirements.

  • Accuracy: ±10% of the FSD
  • Scale: Scale & colour band for LIN, LOX, LAR LCO2 & LNG
  • Case & Dial Size: Engineering polymer: 2.5”
  • Mounting: Direct screwed on tank
  • Maximum Working Pressure: 100 bar / 1500 psi
  • Design Temperatures: -196°C to 80°C (-321°F to 175°F)
  • Housing Material: Aluminium (non-wetted part)
  • Wetted Parts: Brass stem, EPDM ‘O’ring/teflon flat seal, SS302 spring, brass plunger, SS316 plunger rod, RE magnet, SS316 eye hook & aluminium float
  • Seal: EPDM (Std.), Teflon & Viton (on request)
  • Window: Acrylic (std.)
  • Connection: 1/2” BSP(M) (std.), 3/4”-16 UNF(M), (others on request)
Float Level Gauge front 400

DP Gauge (for dewars, microbulks and cylinders)

The precision model 300DGC gauges have a ±2% full scale accuracy. This type of diaphragm model is used in applications where no migration of the media from high pressure side (HP) to low pressure side (LP) is permitted.  Options include oxygen cleaned and switch options, 1 & 2, for remote outputs.

  • Accuracy: ±2% of the FSD
  • Mounting: Direct, front flange, 2” pipe & surface mounting
  • Case material & dial size: Standard:  Stainless steel (SS 304): 50-150mm
  • Maximum Working Pressure: 100 bar / 1500 psi
  • Wetted Parts: Diaphragm, body material, SS 302 spring & ceramic magnet
  • Seal: Buna-N, Viton & EPDM
  • Window: Standard: Float glass with optional toughened glass, acrylic & safety glass
  • Connection: Standard: ¼” NPT(F), Optional: ¼” BSP (F) with adaptor
  • Porting: In-line, rear, bottom, bottom & vent, in-line & vent, in-line & bottom
  • Protection: IP 66 / NEMA-4
  • Range: 0-0.075 to 0-4 bar (0-1 to 0-60 psi)
  • Scale: Standard Pressure unit, Volumetric & weight (need detailed internal tank drawing)
  • Design Temperatures: 0 to 80°C (32 to 175°F)
  • Body Material: Aluminium, Brass, SS 316 & Monel
  • Migration: Zero Migration from high to low port
  • First marking on scale: 15% of the FSD
Differential Pressure Gauge front 400
